Hobbywing Fusion SE 1200KV RC Crawler Motor ESC Waterproof Performance

Fusion SE RC Crawler Powerhouse 1200KV Waterproof Motor ESC

Unleash your inner wanderer with this vintage-inspired treasure a whisper of bygone eras and a dash of modern charm perfect for stashing your essentials or adding a touch of bohemian flair to any outfit its worn-in feel tells a story of adventure and effortless cool a little something special to elevate your everyday vibe

$69.50 $139.00

num:

description

Introducing the all new Hobbywing Fusion SE 1200KV Waterproof Brushless RC Crawler Motor & ESC. This motor and ESC are designed for superior performance and durability at an affordable price. With a wide range of speeds and plenty of torque, it's the perfect combination for navigating terrain and trails.

Features

The integrated design of the ESC and the motor greatly reduces the overall volume and weight, and makes the layout and wiring of car frame simpler and more convenient.
The FOC driving mode, low speed torque is strong. Smooth running at extreme low speed, which is far superior to the common sensored brushless power system, even better than the brushed power.
Thanks to the sine wave driving mode, the whole system has high efficiency, small heat, and effectively extends the endurance time; and the motor runs more quietly and soft.
The protection grade of the whole system is IP67, with excellent waterproof and dustproof performance. Under various weather conditions, the whole system can easily deal with the complex road surface containing silt, ice and snow, and water.
Intelligent torque output and speed closed-loop control, fully experience the cruise control and steep slope slow descent function of 1:1 vehicle, making the control handy
Active drag brake force adjustment, providing super strong parking capacity on slope.
Multiple protection functions: battery low voltage protection, overheat protection, throttle lost protection, lock-up protection.
It supports LED program box to set ESC parameters, and has independent parameter setting interface, which is integrated on electronic switch, making setting parameters more convenient.

Specifications

Application: 1/10th scale rock crawler
Waterproof: IP67 rated
Peak Current: 40A
Battery: 2-3S LiPo or 6-9 Cell NiMH
Motor KV: 1200kv
Diameter 36mm
Length of Motor: / 58.1mm
Shaft diameter 3.175mm
Exposed shaft length: 16.5mm
Motor Poles: 4
Battery connection wires: 14AWG 200mm
Connector: XT60
ESC programming via: LED Program Box
Program Port: Independent programming interface (switch position)
Firmware upgrade not supported
Size 36x58.1mm
Weight 201g (including wires & connectors)

Note: The IP67 protection level mentioned above is splash-resistant, water-resistant and dust-resistant under normal use, and is tested under controlled laboratory conditions. Its effect is in the GB/T 4208-2017 (domestic) / IEC 60529 (overseas) standard to IP67 level. Splash, water and dust resistance are not permanently effective, and the level of protection may decline due to aging. Do not soak for a long time to avoid damaging the product.
